NIKE on Kwajalein

 <--[BACK-to-MAIN-Kwaj-PAGE]-->
Map
Novel set on Kwaj-Sub Zero
Photos of Missiles
LINKS:
.

.....

Gallery

Missiles
Spartan launch from Mount Olympus

Nike Zeus B

Nike Zeus

Rail Launch



Nike Zeus
Specs
Nike Zeus A Nike Zeus B Spartan
Length  13.28m   44ft 3" 14.73m  16.83m
Diameter  0.91m     3ft 0.91m  1.07m
Span 3m          9ft 9" 2.44m  3m
Launch Weight  5,000kg  11,000lb 10,350kg  13,200kg
Range  320km    200 miles 400km  740km
Ceiling  ~280km  560km
1st Stage Motor  TX-135  (450klb thrust)  TX-135  TX-500
2nd Stage Motor  TX-  TX-238  TX-454
3rd Stage Motor  N/A  TX-239  TX-239
Warhead  20kT  400kT  5MT
   .

Sprint

The Sprint's exit velocity was so fast that its skin glowed in the daytime.

Duel Sprint Launch
.
 .
A heavily "airbrushed" photo of an early Sprint Launch
.
....
.
Zeus Acquisition RADAR
 ZAR Receiving Antenna
ZAR Power Plant
ZAR Transmitting Antenna
..
ZAR layout

...

ZAR
The Zeus Acquisition Radar was so powerful
that it used seperate transmitting and receiving antennas.
Foreground: 85 foot diameter Receiving antenna.
Background: ZAR Transmitting antenna enclosed by 90 foot high stainless steel "Beam Forming Fence."
And, in between is the ZAR Power plant.



PAR
Phased Array RADAR

..

Borrowed, Great Photo
 View of the Technical Area & "downtown" Kwaj

Reentry


Daylight Reentry
.

Night Reentry
.







..
